A gem, then a block, then a language, then a data structure

Milestone 1The gem, a Step, and a Registry

Goal

A working gem skeleton with three ideas in it: a Step that describes work, a Registry that knows how to perform it, and an error hierarchy that a user can rescue. No DSL yet.

Concepts

Classes and attr_reader, freezing for immutability, value equality with ==/eql?/hash, duck typing with respond_to?, Hash#fetch with a block, error class hierarchies, and minitest.

Design

The central separation, which the whole course rests on: a Step says what, the Registry says how. A step named :fetch with options {from: "arxiv"} is a description. Whether that means an HTTP call, a fixture file, or a no-op in a dry run is the registry's business. Once those are separate, testing a pipeline stops requiring a network, and users can add verbs without touching your code.

The second decision is that a Step is frozen on construction. Ruby lets you mutate almost anything, and a description that changes between validation and execution is a bug you cannot reproduce. Freezing is how you opt out.

Implementation

lib/automation/errors.rb

# frozen_string_literal: true

module Automation
  # Every error this gem raises inherits from Error, so a user can write
  # `rescue Automation::Error` and catch everything we throw without
  # catching everything in the world.
  class Error < StandardError; end

  # Raised when a pipeline references a step nobody registered.
  class UnknownStep < Error
    attr_reader :name, :known

    def initialize(name, known, location: nil)
      @name = name
      @known = known
      message = +"unknown step #{name.inspect}"
      message << " at #{location}" if location
      message << "; known steps: #{known.sort.join(', ')}" unless known.empty?
      message << "; no steps are registered" if known.empty?
      super(message)
    end
  end

  # Raised when a step implementation fails. Keeps the original as #cause.
  class StepFailed < Error
    attr_reader :step

    def initialize(step, cause)
      @step = step
      super("step #{step.name} failed: #{cause.message} (#{cause.class})")
    end
  end
end

Explanation

• One base class, everything under it. This is not politeness, it is the only way a user can write a correct rescue. A library that raises bare RuntimeError forces its users to rescue everything or nothing.
• +"unknown step ..." — the unary plus returns an unfrozen copy of a frozen string literal. Without it, the << on the next line raises FrozenError, because of the magic comment at the top of the file. This is the frozen-literal rule from Part 2 arriving in real code.
• The error carries data, not just a message. attr_reader :name, :known means a caller can react programmatically (suggest a correction, list alternatives) rather than parsing your English. Go's errors.As exists for exactly this; in Ruby you get it by rescuing the class.
• super(message) passes the constructed message up to StandardError#initialize. Forgetting this gives you an exception whose message is the class name, which is a common and baffling bug.

lib/automation/step.rb

module Automation
  # Step is one instruction in a pipeline: a name, positional arguments and
  # options. It describes work; it does not perform it.
  class Step
    attr_reader :name, :args, :options

    def initialize(name, *args, **options)
      @name = name.to_sym
      @args = args.freeze
      @options = options.freeze
      freeze
    end

    def to_s
      parts = args.map(&:inspect) + options.map { |k, v| "#{k}: #{v.inspect}" }
      "#{name}(#{parts.join(', ')})"
    end

    def ==(other)
      other.is_a?(Step) && name == other.name &&
        args == other.args && options == other.options
    end
    alias eql? ==

    def hash = [self.class, name, args, options].hash
  end
end

Explanation

• name.to_sym normalises at the boundary, so "fetch" and :fetch are the same step forever after. Do this once, at construction, and never think about it again.
• freeze as the last line of initialize makes the object immutable. Note that freezing is shallow: it stops @name = ..., but the Hash in @options needs its own freeze, which is why both appear.
• ==, eql? and hash are three different things and you need all three. == is general equality; eql? is what Hash uses for key lookup; hash must return the same integer for objects that are eql?. Defining == alone means [a, b].uniq silently keeps duplicates.
• alias eql? == is a keyword, not a method call, and takes bare method names.
• to_s is written to reproduce the DSL syntax, so error messages and logs read like the user's own file. It is worth spending five minutes on, and the test below pins it.

lib/automation/registry.rb

module Automation
  # Registry maps step names to implementations. An implementation is
  # anything that responds to #call: a lambda, a method object, or an
  # instance of a class you wrote.
  class Registry
    def initialize
      @steps = {}
    end

    def register(name, callable = nil, &block)
      impl = callable || block
      raise ArgumentError, "register(#{name.inspect}) needs a callable or a block" if impl.nil?
      unless impl.respond_to?(:call)
        raise ArgumentError, "step #{name.inspect} must respond to #call, got #{impl.class}"
      end

      @steps[name.to_sym] = impl
      self
    end

    def fetch(name, location: nil)
      @steps.fetch(name.to_sym) { raise UnknownStep.new(name, known, location: location) }
    end

    def registered?(name) = @steps.key?(name.to_sym)
    def known = @steps.keys
  end
end

Explanation

• callable = nil, &block accepts both register(:fetch) { ... } and register(:fetch, MyStep.new). impl = callable || block takes whichever arrived, and || works because nil is falsy.
• respond_to?(:call) is the duck-typing check, and it is the right one. We do not require a base class or a module. A lambda, a method object (method(:foo)), a class instance with #call, and a curried proc all qualify. Ruby libraries that demand you inherit from their base class are usually a design smell.
• @steps.fetch(name) { raise ... } — fetch with a block calls the block when the key is missing, so we raise our error with a useful message instead of a bare KeyError. This one line is most of what makes a DSL pleasant to use.
• register returns self so calls can chain.

The tests

class StepTest < Minitest::Test
  def setup
    @step = Automation::Step.new("fetch", "papers", from: "arxiv")
  end

  def test_name_is_always_a_symbol
    assert_equal :fetch, @step.name
    assert_equal :fetch, Automation::Step.new(:fetch).name
  end

  def test_is_frozen_all_the_way_down
    assert @step.frozen?
    assert @step.options.frozen?
    assert_raises(FrozenError) { @step.options[:from] = "elsewhere" }
  end

  def test_value_equality_and_hashing
    twin = Automation::Step.new(:fetch, "papers", from: "arxiv")
    assert_equal twin, @step
    assert_equal 1, [@step, twin].uniq.size
    refute_equal Automation::Step.new(:fetch, "papers", from: "other"), @step
  end

  def test_to_s_reads_like_the_dsl
    assert_equal 'fetch("papers", from: "arxiv")', @step.to_s
  end
end

$ ruby -Ilib -Itest test/test_step.rb
4 runs, 9 assertions, 0 failures, 0 errors, 0 skips

Note [@step, twin].uniq.size: that assertion is the one that fails if you define == and forget hash. Tests that pin the consequences of a protocol, rather than the protocol itself, catch more.

class Registry
  include Enumerable

  def each(&block)
    return to_enum(:each) unless block_given?

    @steps.each(&block)
    self
  end

  def describe(name)
    impl = fetch(name)
    required = impl.parameters.select { |type, _| type == :keyreq }.map(&:last)
    optional = impl.parameters.select { |type, _| type == :key }.map(&:last)
    rest     = impl.parameters.any? { |type, _| type == :keyrest }

    parts = []
    parts << "requires: #{required.join(', ')}" unless required.empty?
    parts << "accepts: #{optional.join(', ')}"  unless optional.empty?
    parts << "accepts any options"              if rest
    "#{name}(#{parts.join('; ')})"
  end
end

registry.register(:fetch) { |_input, what, from:, since: "1d"| }
registry.describe(:fetch)
# => "fetch(requires: from; accepts: since)"

registry.count                      # => 1
registry.map { |name, _| name }     # => [:fetch]
registry.sort_by { |name, _| name } # => [[:fetch, #<Proc...>]]

Experiment

Remove freeze from Step#initialize and run the suite: one test fails with a clear message. Now remove only the .freeze on @options and run again: the object is frozen but its Hash is not, so @step.options[:from] = "x" succeeds. That is shallow freezing, and it is the reason Data in Milestone 4 is worth having, since it freezes what it holds.

Checkpoint

1. Why does Step freeze both itself and its options Hash?
2. What breaks if you define == but not hash?
3. Why does Registry#register check respond_to?(:call) rather than the class?
4. What does Hash#fetch with a block do that Hash#[] does not?
5. Why must every error in a gem inherit from one base class?

Milestone 2Blocks: the DSL with its receiver showing

Goal

Automation.pipeline("research") do |p| ... end builds a runnable pipeline. The builder is an explicit block parameter, which is deliberately one step short of the DSL we want, because the difference between this and Milestone 3 is the entire lesson.

Concepts

yield and block parameters, reduce as an interpreter, exception wrapping with automatic cause, and the difference between a build-time and a run-time error.

Design

Three objects, each with one job:

  Automation.pipeline(name) { |p| ... }
        │
        ├─ creates a Builder, hands it to the block
        │
        ├─ Builder#step collects Step descriptions
        │
        └─ Builder#to_pipeline produces a frozen Pipeline

  Pipeline#run  →  reduce over the steps, looking each one up

The interpreter is one line, and it is worth seeing before it gets dressed up: a pipeline is a fold. Each step takes the previous step's output and returns the next input. That single decision (values flow through, nothing is shared) is what makes steps composable and testable, and it is the same reasoning that made Go's Action a pointer-free value.

Implementation

module Automation
  class Pipeline
    attr_reader :name, :steps

    def initialize(name, steps, registry: Automation.registry)
      @name = name.to_sym
      @steps = steps.freeze
      @registry = registry
      freeze
    end

    def run(input = nil)
      @steps.reduce(input) { |acc, step| perform(step, acc) }
    end

    private

    def perform(step, input)
      impl = @registry.fetch(step.name)
      impl.call(input, *step.args, **step.options)
    rescue StandardError => e
      raise e if e.is_a?(Error)
      raise StepFailed.new(step, e)
    end
  end

  class Builder
    def initialize(name)
      @name = name
      @steps = []
    end

    def step(name, *args, **options)
      @steps << Step.new(name, *args, **options)
      self
    end

    def to_pipeline(registry:) = Pipeline.new(@name, @steps, registry: registry)
  end

  def self.pipeline(name, registry: self.registry)
    builder = Builder.new(name)
    yield builder
    builder.to_pipeline(registry: registry)
  end
end

Explanation

• yield builder calls the block with the builder as its parameter. The block's return value is discarded: what matters is the mutations it made to the builder. That is the builder pattern, and it is the only DSL technique in this milestone.
• impl.call(input, *step.args, **step.options) — the splat and double splat expand here, the mirror image of how they collected in Step#initialize. So a step registered as { |input, what, from:| } receives the accumulated value, then the positional arguments, then the keywords.
• rescue StandardError => e inside a method with no begin: a method body is an implicit begin block.
• raise e if e.is_a?(Error) lets our own errors pass through unwrapped. Without it, UnknownStep would be re-wrapped as StepFailed and the user would see a confusing double message. Deciding what not to wrap is half of good error handling.
• raise StepFailed.new(step, e) inside a rescue sets e.cause automatically to the original exception. Ruby maintains that chain for you; there is no %w to remember.

Running it

Automation.register(:fetch) do |_input, source, from:|
  puts "  fetching #{source} from #{from}"
  ["Attention Is All You Need (AI)", "Cats sleep a lot (biology)", "Scaling laws (AI)"]
end

Automation.register(:filter)    { |items, topic:| items.select { |i| i.include?(topic) } }
Automation.register(:summarize) { |items, max_words:| items.map { |i| i.split.first(max_words).join(" ") + "..." } }

research = Automation.pipeline("research") do |p|
  p.step :fetch, "papers", from: "arxiv"
  p.step :filter, topic: "AI"
  p.step :summarize, max_words: 3
end

puts research
p research.steps.map(&:to_s)
p research.run

research (3 steps)
["fetch(\"papers\", from: \"arxiv\")", "filter(topic: \"AI\")", "summarize(max_words: 3)"]
  fetching papers from arxiv
["Attention Is All...", "Scaling laws (AI)..."]

Two failure paths, also real output:

--- an unregistered step fails at run time, not build time ---
built fine: broken (1 steps)
run failed: unknown step :summarise; known steps: fetch, filter, summarize

--- a failing step is wrapped, with the cause preserved ---
Automation::StepFailed: step explode failed: divided by 0 (ZeroDivisionError)
cause: ZeroDivisionError

Read the first one carefully, because it is the flaw that drives Milestone 4. A pipeline containing a typo builds successfully and fails only when that step executes. If :summarise were the fourth step of an hour-long job, you would find out in an hour. Go would have caught this at compile time. We will catch it with a validator, which is Ruby's equivalent: not free, but available.

YAML                              Ruby builder
────                              ────────────
steps:                            Automation.pipeline("research") do |p|
  - name: fetch                     p.step :fetch, "papers", from: "arxiv"
    from: arxiv                     p.step :filter, topic: "AI"
  - name: filter                  end
    topic: AI

static, safe to parse            executable, arbitrary code
needs a schema to validate       can validate with reflection
no loops, no variables           3.times { |i| p.step :fetch, page: i }
no editor support for values     completion, refactoring, debugger
errors: "line 7: bad key"        errors: a Ruby backtrace

class Pipeline
  def |(other)
    unless other.is_a?(Pipeline)
      raise ArgumentError, "cannot compose a Pipeline with #{other.class}"
    end
    if registry_of(other) != @registry
      raise Error, "cannot compose pipelines using different registries"
    end

    Pipeline.new(:"#{name}_#{other.name}", steps + other.steps, registry: @registry)
  end
  alias + |

  def repeat(times)
    raise ArgumentError, "times must be positive" unless times.positive?

    Pipeline.new(:"#{name}_x#{times}", steps * times, registry: @registry)
  end

  protected

  # protected, not private: readable by other Pipelines, not by outsiders.
  def registry_of(other) = other.instance_variable_get(:@registry)
end

combined = fetching | processing
combined.steps.map(&:name)   # => [:fetch, :filter, :summarize]
fetching.steps.map(&:name)   # => [:fetch]   (unchanged)

Experiment

Register a step that returns nil and put it in the middle of a pipeline. Then watch the next step receive nil and fail with something unhelpful like undefined method 'select' for nil. The fold is unforgiving: every step must return something the next one can use. This is the argument for the Context object that Milestone 5 introduces, where the value flowing through is a structured thing with a payload and metadata rather than a bare return value.

Checkpoint

1. What does yield builder do, and what happens to the block's return value?
2. Explain impl.call(input, *step.args, **step.options) in terms of how Step collected them.
3. Why does perform re-raise errors that are already Automation::Error?
4. Where does e.cause come from, and what is the Go equivalent?
5. Why is a typo in a step name not caught until run time?

Milestone 3instance_eval: what it buys, and what it costs

Goal

Remove the receiver, so the block reads as a language:

Automation.define_pipeline("research") do
  fetch "papers", from: "arxiv"
  filter topic: "AI"
  summarize max_words: 3
end

Then find the three ways this breaks, watch each one break for real, and fix them.

Concepts

instance_eval, self and the implicit receiver, method_missing with respond_to_missing?, BasicObject, and delegating to the caller via block.binding.receiver.

Design

The mechanism is one line: builder.instance_eval(&block) runs the block with self set to the builder, so fetch "papers" is a message to the builder. The builder has no fetch method, so method_missing catches it and records a step.

That is the whole of the good news. The bad news has three parts, and every Ruby DSL author meets all three:

1. Your caller's methods vanish. self is now the builder, so a helper method on the object where the block was written is no longer reachable.
2. Object's own methods shadow your verbs. A builder is an Object, so it already responds to format, print, select, method, hash, display, test and about fifty others. method_missing never fires for those, so a step with a colliding name silently does something else.
3. Typos become steps. If method_missing accepts everything, a misspelling is recorded as a perfectly valid step that fails much later.

Let us watch all three happen.

The naive version, and its failures

class NaiveDSL
  def initialize(name)
    @name = name
    @steps = []
  end

  def method_missing(verb, *args, **options, &_block)
    @steps << Step.new(verb, *args, **options)
    self
  end

  def respond_to_missing?(_verb, _include_private = false) = true

  def steps = @steps
end

Failure 1: the caller's helper is captured as a step

class Report
  def initialize(topic) = @topic = topic
  def default_topic = @topic          # a helper on the OUTER object

  def naive
    dsl = Automation::NaiveDSL.new("r")
    dsl.instance_eval do
      filter topic: default_topic     # self is the builder now
    end
    dsl.steps
  end
end

p Report.new("AI").naive.map(&:to_s)

["default_topic()", "filter(topic: #<Automation::NaiveDSL:0x00007f754b7183c0 @name=\"r\",
 @steps=[#<Automation::Step:0x00007f754b718118 @name=:default_topic, ...>]>)"]

Look at what happened. default_topic was not a NoMethodError; it was captured by method_missing and became a step called default_topic. Then, because method_missing returns self, its return value was the builder, which got passed as the topic: option of the next step. The user asked for one step and got two, one of which contains a builder as data.

This is the worst kind of bug: no exception, no warning, a plausible-looking result, and a failure that surfaces somewhere else entirely. It is the price of method_missing accepting everything.

Failure 2: a step name that collides with an Object method

Automation.register(:format) { |items| items.map(&:upcase) }

naive = Automation::NaiveDSL.new("collide")
naive.instance_eval { format "%s", "x" }    # Kernel#format wins, silently
p naive.steps.map(&:to_s)

[]

No step at all. Kernel#format exists on every object, so the method was found and method_missing never ran. The user's format step vanished without a trace. Every name on Object is a landmine: p, print, puts, select, test, method, display, hash, send, class, freeze, trust, then, tap.

The version we keep

  # DSLBuilder is the version we keep. Two changes from NaiveDSL:
  #
  #   1. It inherits from BasicObject, which has almost no methods, so a
  #      step named `format` or `print` is not silently swallowed by
  #      Object's own methods.
  #   2. It remembers the object the block was written in, and forwards
  #      anything that is not a registered step back to it, so helper
  #      methods from the caller still work inside the block.
  class DSLBuilder < BasicObject
    def initialize(name, outer, registry)
      @name = name
      @outer = outer
      @registry = registry
      @steps = []
    end

    def method_missing(verb, *args, **options, &block)
      if !@registry.registered?(verb) && @outer.respond_to?(verb, true)
        return @outer.__send__(verb, *args, **options, &block)
      end

      @steps << ::Automation::Step.new(verb, *args, **options)
      self
    end

    def respond_to_missing?(verb, include_private = false)
      @registry.registered?(verb) || @outer.respond_to?(verb, include_private)
    end

    # Deliberately ugly names: anything readable might collide with a step.
    def __steps__ = @steps
  end

  def self.define_pipeline(name, registry: self.registry, &block)
    raise ArgumentError, "define_pipeline needs a block" unless block

    outer = block.binding.receiver
    builder = DSLBuilder.new(name, outer, registry)
    builder.instance_eval(&block)
    Pipeline.new(name, builder.__steps__, registry: registry)
  end

Explanation

• < BasicObject is the fix for collisions. BasicObject has about eight methods (__send__, __id__, equal?, instance_eval, instance_exec, method_missing and a couple more), so nearly every name falls through to method_missing. The cost: no puts, no raise, no constant lookup, which is why the code says ::Automation::Step with a leading :: and ::Kernel.caller_locations later. Those leading colons are not style; without them the constant is not found.
• block.binding.receiver is the fix for vanished helpers. Every block carries a Binding: the environment where it was written, including self. receiver gives us that original self, so we can forward anything we do not recognise back to it. This is how a block written inside a Report can still call the report's methods.
• The order of the check matters. !@registry.registered?(verb) && @outer.respond_to?(verb, true) means a registered step always wins, and only unrecognised names are forwarded. Reverse it and a user whose class happens to define filter would find their DSL silently broken.
• respond_to?(verb, true) — the second argument includes private methods. Helper methods in a class are often private, and top-level defs are private methods on Object, so without the true the forwarding misses most of what people actually write.
• __send__ rather than send, and __steps__ rather than steps: in a BasicObject-derived DSL every ordinary name is a name your users might want as a verb. The double underscores are the convention for "this is plumbing, please do not name a step this".

Both fixes, working

--- 1. bare verbs, no receiver ---
["fetch(\"papers\", from: \"arxiv\")", "filter(topic: \"arxiv\")", "summarize(max_words: 2)"]
["papers from"]

--- 2. local variables still work (the block is a closure) ---
["fetch(\"papers\", from: \"arxiv:cs.AI\")", "summarize(max_words: 2)"]

--- 3. the caller's own methods: broken, then fixed by delegation ---
["default_topic()", "filter(topic: #<Automation::NaiveDSL...>)"]      # naive
["filter(topic: \"AI\")"]                                              # delegating

--- 4. a step whose name collides with an Object method ---
[]                                                                    # naive
["format()"]                                                          # BasicObject

Section 2 of that output is worth a moment: instance_eval changes self, but the block is still a closure, so local variables from the enclosing scope (source, limit) remain visible. Methods and locals behave differently, and knowing which is which is most of understanding Ruby scope.

And because the block is ordinary Ruby, control flow comes free:

pipeline = Automation.define("x") do
  puts "  (puts works inside the block: forwarded to the outer self)"
  3.times { |i| summarize index: i }
end

p pipeline.step_names
p pipeline.steps.map { |s| s.options[:index] }

  (puts works inside the block: forwarded to the outer self)
[:summarize, :summarize, :summarize]
[0, 1, 2]

Three steps generated by a loop. That is the whole argument for an executable DSL over a data format, in four lines: no for_each: key to invent, no template language, no escaping rules. Your users already know how to write a loop.

Automation.define_pipeline("research") do
  fetch "papers", from: "arxiv"

  group "cleaning" do
    deduplicate
    normalize case: :lower
  end

  summarize max_words: 200
end

class DSLBuilder < BasicObject
  def initialize(name, outer, registry, path = [])
    @name = name
    @outer = outer
    @registry = registry
    @path = path
    @steps = []
  end

  def group(group_name, &block)
    # A nested builder: same outer, same registry, deeper path.
    nested = DSLBuilder.new(group_name, @outer, @registry, @path + [group_name.to_s])
    nested.instance_eval(&block)
    @steps.concat(nested.__steps__)
    self
  end

  def method_missing(verb, *args, **options, &block)
    if !@registry.registered?(verb) && @outer.respond_to?(verb, true)
      return @outer.__send__(verb, *args, **options, &block)
    end

    @steps << ::Automation::Step.new(
      verb, *args, **options.merge(__path__: (@path + [verb.to_s]).join("/"))
    )
    self
  end
end

Experiment

Make DSLBuilder inherit from Object instead of BasicObject and register a step called :p or :test. Then try to use it. Then change it back and note the :: prefixes you suddenly need. Finally, run BasicObject.instance_methods.sort and Object.instance_methods.size in irb and compare: 8 methods against 58 or so. That difference is the entire cost and benefit.

Checkpoint

1. What exactly does instance_eval change, and what does it leave alone?
2. Why did default_topic become a step in the naive version, and why is that worse than an exception?
3. Why did the format step disappear entirely, and what fixes it?
4. What is a Binding, and what does block.binding.receiver give you?
5. Why does the registry check come first in method_missing?
6. Give one situation where the explicit builder is the better design.

Milestone 4Stop executing. Build a data structure.

Goal

The DSL produces an immutable AST that records where every step was written. A validator checks the whole pipeline against the registry before anything runs, reporting problems with file and line. A pipeline can be converted to plain data and back, which gives us a safe mode for untrusted input.

Concepts

Data.define for AST nodes, caller_locations for source tracking, reflection on parameters to check arguments, immutable transformation, and serialisation as a security boundary.

Design

Milestone 2's Pipeline mixes three responsibilities: it describes the steps, it holds the registry, and it runs. Separating them gives us four things we cannot otherwise have:

So the AST becomes the centre of the system, and everything else is a function over it:

   block ──► ASTBuilder ──► PipelineNode ──┬──► Validator  ──► problems
                            (frozen Data)  ├──► Runner     ──► results
                                           ├──► to_h       ──► plain data
                                           └──► transforms ──► a NEW PipelineNode
   data  ──► from_h ────────►┘  (no code executed, ever)

Implementation

lib/automation/ast.rb

module Automation
  # The AST. Every node is a Data object: immutable, value-compared, and
  # carrying the source location it came from so errors can point at the
  # user's file rather than at ours.
  module AST
    StepNode = Data.define(:name, :args, :options, :location) do
      def to_s
        parts = args.map(&:inspect) + options.map { |k, v| "#{k}: #{v.inspect}" }
        "#{name}(#{parts.join(', ')})"
      end

      def to_h = { name: name, args: args, options: options, location: location }
    end

    HandlerNode = Data.define(:kind, :callable, :location)

    PipelineNode = Data.define(:name, :steps, :handlers, :location) do
      def step_names = steps.map(&:name)
      def find(name) = steps.find { |s| s.name == name.to_sym }
      def handler(kind) = handlers.find { |h| h.kind == kind }

      def to_h
        { name: name, location: location,
          steps: steps.map(&:to_h), handlers: handlers.map(&:kind) }
      end

      # Returns a NEW pipeline: transformations never mutate.
      def with_steps(new_steps) = with(steps: new_steps.freeze)

      def insert_before(name, node)
        index = steps.index { |s| s.name == name.to_sym }
        raise Error, "no step named #{name.inspect} in #{self.name}" if index.nil?

        with_steps(steps.dup.insert(index, node))
      end
    end
  end
end

Explanation

• Data.define(:name, :args, :options, :location) creates a class with readers, keyword construction, value equality, hash, a readable inspect and frozen instances. Compare with the hand-written Step in Milestone 1: same guarantees, a quarter of the code, and no chance of forgetting hash.
• The block passed to Data.define is a class body. Methods defined in it become instance methods of the new class. This is the same "class bodies are executable code" idea from Part 2, used as an API.
• with(steps: ...) comes free with Data: it produces a copy with some fields changed. Every transformation in this project is built from it, and none of them mutate.
• insert_before returns a new pipeline. The original is still valid, still frozen, still safe to hold. That matters when Milestone 11 lets pipelines rewrite themselves mid-run: a transformation that goes wrong damages nothing.

Capturing source locations

    def method_missing(verb, *args, **options, &block)
      if !@registry.registered?(verb) && @outer.respond_to?(verb, true)
        return @outer.__send__(verb, *args, **options, &block)
      end

      @steps << ::Automation::AST::StepNode.new(
        name: verb, args: args.freeze, options: options.freeze, location: __where__
      )
      self
    end

    private

    # Two frames up: method_missing -> the user's line.
    def __where__
      frame = ::Kernel.caller_locations(2, 1).first
      "#{::File.basename(frame.path)}:#{frame.lineno}"
    end

caller_locations(start, length) returns frames from the call stack as objects with path, lineno and label. Counting the frames is fiddly and worth doing by experiment: frame 1 is method_missing itself, frame 2 is the line in the user's block that triggered it. Get it wrong and every step reports the same location inside your own library, which looks plausible and is useless.

This is the single highest-value feature in the milestone. A DSL that can say demo4.rb:29: unknown step :summarise feels like a compiler. A DSL that says NoMethodError in automation/runner.rb:31 feels like a leaky abstraction. The difference is six lines.

The validator, using reflection as a type check

  class Validator
    def initialize(registry)
      @registry = registry
    end

    def problems(pipeline)
      pipeline.steps.flat_map { |step| problems_for(step) }
    end

    def validate!(pipeline)
      found = problems(pipeline)
      raise InvalidPipeline, found unless found.empty?

      pipeline
    end

    private

    def problems_for(step)
      unless @registry.registered?(step.name)
        return ["#{step.location}: unknown step #{step.name.inspect} " \
                "(known: #{@registry.known.sort.join(', ')})"]
      end

      params = @registry.fetch(step.name).parameters
      missing_keywords(step, params) + unknown_keywords(step, params)
    end

    def missing_keywords(step, params)
      required = params.select { |type, _| type == :keyreq }.map(&:last)
      (required - step.options.keys).map do |key|
        "#{step.location}: step #{step.name} is missing required option #{key.inspect}"
      end
    end

    def unknown_keywords(step, params)
      return [] if params.any? { |type, _| type == :keyrest } # accepts **rest

      allowed = params.select { |type, _| %i[key keyreq].include?(type) }.map(&:last)
      (step.options.keys - allowed).map do |key|
        hint = allowed.empty? ? "it takes no options" : "it accepts: #{allowed.join(', ')}"
        "#{step.location}: step #{step.name} got unknown option #{key.inspect}; #{hint}"
      end
    end
  end

This is the part that answers Part 0's honest criticism. Ruby cannot check your program before it runs, but a program can check itself, because every callable can be asked what arguments it wants. parameters returns pairs like [[:opt, :items], [:keyreq, :topic], [:key, :since]], and from that you can derive: which options are required, which are permitted, and whether the step accepts anything at all via **rest.

Details that make it usable rather than merely correct:

• Collect every problem, do not stop at the first. flat_map over all steps and raise once with the whole list. A validator that reports one error per run is a validator people run once and then ignore.
• Every message names a location and suggests an alternative. "unknown option :limit; it accepts: topic" is actionable; "invalid options" is not.
• The keyrest escape hatch is deliberate. A step written as { |input, **opts| } opts out of checking, which is the right behaviour for genuinely open-ended steps and a useful pressure toward declaring your options.
• InvalidPipeline carries problems as data, so a CLI can format them differently from a test.

What it looks like

--- the pipeline is data ---
research (4 steps, 0 handlers)
[:fetch, :filter, :summarize, :save_to]
{:name=>:research,
 :location=>"demo4.rb:11",
 :steps=>
  [{:name=>:fetch, :args=>["papers"], :options=>{:from=>"arxiv"}, :location=>"demo4.rb:12"},
   {:name=>:filter, :args=>[], :options=>{:topic=>"arxiv"}, :location=>"demo4.rb:13"},
   {:name=>:summarize, :args=>[], :options=>{:max_words=>3}, :location=>"demo4.rb:14"},
   {:name=>:save_to, :args=>["knowledge_base"], :options=>{}, :location=>"demo4.rb:15"}],
 :handlers=>[]}

--- nothing has executed yet; now it runs ---
  saved 1 items to knowledge_base
["papers from arxiv"]

--- validation catches mistakes before anything runs ---
pipeline is invalid:
  - demo4.rb:28: step fetch is missing required option :from
  - demo4.rb:29: unknown step :summarise (known: fetch, filter, save_to, summarize)
  - demo4.rb:30: step filter got unknown option :limit; it accepts: topic

--- building executes nothing, even for steps that would explode ---
built a pipeline containing :explode and nothing happened

--- when_failed runs the user's handler ---
  handler: explode failed with boom

--- transformations return new pipelines ---
[:fetch, :filter, :summarize, :save_to]
[:fetch, :filter, :deduplicate, :summarize, :save_to]

--- the data-only path: no code, no eval ---
[:fetch, :summarize]
["papers from"]

Three errors, each with the user's own file and line, reported together, before a single step ran. Compare that with Milestone 2, where the same pipeline would have fetched successfully and then failed on the typo. That is what the AST bought.

The safe mode

  # The safe path: build the same AST from plain data, with no code
  # execution at all. This is what you expose to untrusted input.
  def self.from_h(hash)
    steps = hash.fetch(:steps, []).map do |s|
      AST::StepNode.new(
        name: s.fetch(:name).to_sym,
        args: (s[:args] || []).freeze,
        options: (s[:options] || {}).transform_keys(&:to_sym).freeze,
        location: s[:location] || "(data)"
      )
    end
    AST::PipelineNode.new(
      name: hash.fetch(:name).to_sym, steps: steps.freeze,
      handlers: [].freeze, location: hash[:location] || "(data)"
    ).freeze
  end

The tests that matter

  def test_building_executes_nothing
    ran = false
    @registry.register(:side_effect) { ran = true }

    Automation.define("dangerous", registry: @registry) { side_effect }

    refute ran, "building a pipeline must not run any step"
  end

  def test_every_step_records_where_it_was_written
    pipeline = Automation.define("located", registry: @registry) do
      fetch "papers", from: "arxiv"
    end

    assert_match(/test_define\.rb:\d+/, pipeline.find(:fetch).location)
  end

  def test_transformations_return_a_new_pipeline
    pipeline = Automation.define("t", registry: @registry) { summarize }
    node = Automation::AST::StepNode.new(name: :fetch, args: [], options: {}, location: "(test)")

    extended = pipeline.insert_before(:summarize, node)

    assert_equal %i[summarize], pipeline.step_names, "the original must not change"
    assert_equal %i[fetch summarize], extended.step_names
  end

  def test_caller_methods_are_forwarded_not_captured_as_steps
    pipeline = Automation.define("delegating", registry: @registry) do
      summarize max_words: helper_value
    end

    assert_equal 7, pipeline.find(:summarize).options[:max_words]
    assert_equal %i[summarize], pipeline.step_names
  end

  def helper_value = 7

$ ruby -Ilib -Itest test/all.rb
....................

20 runs, 50 assertions, 0 failures, 0 errors, 0 skips

test_building_executes_nothing is the invariant test of this course, the equivalent of Go's food conservation. It is two lines and it pins the architectural decision everything else depends on. If someone later "optimises" the builder by executing a step eagerly, this test is what stops them.

Note also test_caller_methods_are_forwarded_not_captured_as_steps: it is the naive-version failure from Milestone 3, turned into a regression test. Every bug you find by hand should become a test before you fix it, and a DSL's failures are especially worth pinning because they are silent.

PipelineNode = Data.define(:name, :steps, :handlers, :location) do
  # Equality ignoring provenance, for round-trip tests and diffs.
  def same_shape?(other)
    other.is_a?(PipelineNode) &&
      name == other.name &&
      steps.map { |s| [s.name, s.args, s.options] } ==
        other.steps.map { |s| [s.name, s.args, s.options] }
  end
end

def self.from_json(text, max_steps: 100)
  from_h(JSON.parse(text, symbolize_names: true), max_steps: max_steps)
end

SAFE_NAME = /\A[a-z_][a-z0-9_]*\z/
SAFE_SCALARS = [String, Integer, Float, TrueClass, FalseClass, NilClass].freeze

def self.from_h(hash, max_steps: 100)
  raw = hash.fetch(:steps, [])
  raise UnsafePipeline, "too many steps: #{raw.size} > #{max_steps}" if raw.size > max_steps
  raise UnsafePipeline, "handlers are not allowed in data pipelines" if hash[:handlers]&.any?

  steps = raw.map do |s|
    name = s.fetch(:name).to_s
    unless name.match?(SAFE_NAME)
      raise UnsafePipeline, "step name #{name.inspect} is not a plain identifier"
    end
    (s[:options] || {}).each do |key, value|
      unless safe_value?(value)
        raise UnsafePipeline, "step #{name}: option #{key} has unsupported value #{value.class}"
      end
    end
    # ... build the StepNode
  end
  # ...
end

def self.safe_value?(value)
  case value
  when *SAFE_SCALARS then true
  when ::Array then value.all? { |v| safe_value?(v) }
  when ::Hash  then value.all? { |k, v| safe_value?(k) && safe_value?(v) }
  else false
  end
end

Experiment

Change caller_locations(2, 1) to caller_locations(1, 1) and look at what the locations become: every step now reports a line inside define.rb. Then try 3 and watch them all point at the line that called Automation.define. Getting this right is pure experiment, and it is worth doing once so that you know how to fix it in your own libraries.

Checkpoint

1. Name four capabilities that only exist because building and running are separate.
2. What does Data.define give you that the hand-written Step class did not?
3. How does the validator know which options a step accepts?
4. Why does caller_locations(2, 1) use 2?
5. Why does a step declared with **opts skip option checking, and is that a bug?
6. What makes from_h safe for untrusted input, and what would make it unsafe again?
7. Why must insert_before return a new pipeline rather than mutating?

Repository state after Milestone 4

automation/
├── Gemfile, automation.gemspec, Rakefile, README.md
├── lib/
│   ├── automation.rb            requires, global registry, register/reset
│   └── automation/
│       ├── version.rb
│       ├── errors.rb            Error, UnknownStep, StepFailed, InvalidPipeline
│       ├── step.rb              milestone 1's frozen value object
│       ├── registry.rb          name -> callable, with useful failures
│       ├── pipeline.rb          milestone 2: builder + reduce interpreter
│       ├── dsl.rb               milestone 3: NaiveDSL and DSLBuilder
│       ├── ast.rb               StepNode, HandlerNode, PipelineNode (Data)
│       ├── define.rb            ASTBuilder, Automation.define, from_h
│       ├── validator.rb         problems with file:line
│       └── runner.rb            a minimal interpreter over the AST
└── test/
    ├── test_helper.rb
    ├── test_step.rb             value semantics, freezing
    ├── test_registry.rb         duck typing, useful errors
    ├── test_define.rb           locations, immutability, nothing executes
    └── test_validator.rb        every validation rule

$ ruby -Ilib -Itest test/all.rb
20 runs, 50 assertions, 0 failures, 0 errors, 0 skips
$ git commit -am "milestone 4: an AST, source locations, and a validator"

Note that pipeline.rb and dsl.rb are still there. Keep them: they are the Milestone 2 and 3 designs, they still pass their tests, and a reader of your repository can follow the same progression you did. Deleting the earlier versions is throwing away the argument.
